18m Locking Mast-230kg Payloads
    Publish time 2014-07-18 17:26
Item #: PHT-90A08180 18m extended height, 230kgs head loads, locking collar style 3.5m retracted height, 8 sections, section dia. 118mm~279mm

18m Lockable Pneumatic Telescopic Masts for Telecommunication Tower

Item code: PHT-90A08180

1> Working pressure: 35 PSI maximum;

2> Vertical Head load: 230Kg(Max);

3> Height Retracted: 3500mm;

4> Height Extended: 18000mm;

5> Number of Tubes:  8;

6> Section Dia. 118mm~279mm

7> Material: Heat Treated Aluminum Alloy 6063B/T6;

8> Default Accessories: 1x top flange, 1x bottom flange, 1x air hose pipe

9> Basic Weight of Mast 300 kgs

10> Optional accessories: guying ropes 3 x 4 (3 layer and 4 ways), electric air compressor, side mounting bracket,  tripod ground mounting bracket, head protect cover, air control manual panel
