15m Pneumatic telescopic mast 70kg payload
Item #: PHT-80109150
Extended Height: 15m/49.2'
Retracted Height: 2.9m/9.5'
Payload: 70kg/154 lbs
Working Air Pressure: 0.2Mpa/29PSI
Working Temperature: -55~85℃
Number of sections: 9 sections
Section Diameter: 66mm~229mm/ 2.6"~9.02"
Mast Weight: 170kgs/374 lbs approx.
Accessories: Top flange, bottom flange, air hose pipe
Guying Lines Recommended 3x4
120 km/h wind resistant
