6m Fire-fighting Truck Mounted Lighting Tower
    Publish time 2015-03-17 11:28
Item #: PHT-FF-6000 6m Pneumatic Telescopic Masts with Internal Spiral Cables for Lighting. 1.75m Retracted Height 3x150W LED Flood Lights Unit/ AC220V/50Hz power supply System control box: control mast extend/retract/ lights light on/off
6m Fire-fighting Truck Mounted Lighting Tower

6m Fire Fighting Truck Mount Lighting Tower

Item #: PHT-FF-6000

System include:

  • 6m Pneumatic Telescopic Masts with Internal Spiral Cables for Lighting. 1.75m Retracted Height
  • 3x150W LED Flood Lights Unit/AC220V/50Hz
  • System control box: control mast extend/retract/lights light on/off


Specification:

Pneumatic Telescopic Masts:

Item #: PHT-70505060

1> Extended Height: 6m

2> Retracted Height: 1.75m

3> Internal Cables: 2x2.5mm2+4x1.5mm2

4> Payloads: 70kg max.

5> Working Pressure: 0.2Mpa/29PSI max.

6> Working Temperature range: Default -250C ~850C (-500C ~850C available)

7> Number of Sections: 5 sections

8> Section Dia.: 66mm~140mm

9> Materials: Anodized Aluminum Pipes Materials AL6063/T5

10> Default Accessories: 1x top flange, 1x bottom flange, 1x air hose pipe

11> Mast Weight: 50 kgs approx.

12> Optional Accessories: electric air compressor, lamps, pan tilt units, side mounting brackets, tripod ground mound mounting bracket


13> LED Flood Lights: 3x150W LED

150W LED Flood Lights
