4.5m Lockable CCTV Mast
    Publish time 2015-03-27 20:09
Item #: CCTV-90603045 4.5m Locking CCTV Mast Internal Spiral Cables for CCTV and Lighting Maximum 100kg payloads 1.8m Retracted Height, 3 sections, base section dia. 118mm,  Mast weight 30kg approx.
4.5m Lockable CCTV Mast

CCTV Mast,Security Mast,Camera Mast,Vedio Mast,Surveillance Mast

1> Item #: CCTV-90603045

2> Internal Spiral Cables: 2x2.5mm2+2x1.5mm2+1xCAT5E cable+1xRG59 Coaxial Video Cable 75 Ohm

3> Extended Height: 4.5m (14.8 ft)

4> Retracted Height: 1.8m (5.9 ft)

5> Maximum Head Loads: 100kg  (220 lbs) head loads

6> Working air pressure: 0.2Mpa/29PSI

7> Working temperature:0~650C

8> Number of sections: 3 sections

9> Base section Dia. 118mm (4.65 inch)

10> Materials: Aluminum Alloy 6063/T5

11> Mast Weight: approx. 30kg ( 88 lbs )

12> Accessories: Top flange, bottom flange, air hose pipe

Optional Accessories:

DC 12V electric air compressor

DC24V electric air compressor

AC220~240V, 50/60Hz

Air control panel with air filters

side mounting brackets

tripod ground mounting brackets
